Lathe chucks


PNEUMATIC CHUCKS SERIES

SOLID ROTARY AIR
CYLINDER

UNT : mm
SPEC.
/ MODEL
A
B
C
D
E
(h7)
F
G
(h8)
H
J
K
L
M
N
P
max.
P
min.
Q
LA-130
130
15
160
90
65
25
17
M16
30
165
95
70
106.5
45
30
6-M8*16
LA-170
170
20
200
100
80
25
17
M16
30
181
95
86
122.5
40
20
6-M10*18
LA-220
220
25
255
130
110
30
21
M20
35
194
95
99
135.5
45
20
6-M12*20


SPEC.
/ MODEL
Piston stroke
(mm)
Max.Speed
(r.p.m)
GrossWeight
(kg)
GD2
(kgf/m2)
Max.Push
Force
(kgf)
Max.Ppeed
Pressure
(kgf/cm2)
Piston Aera(cm2)
Push
Side
Pull
Side
LA-130
15
5000
5.2
0.05
970
8
131.2
124.7
LA-170
20
5000
8.5
0.18
1710
8
225.4
219.0
LA-220
25
4000
11.6
0.36
2890
8
378.6
369.3




PULL BACK
CHUCK FIXTURES
NEW

UNT : mm
SPEC.
/ MODEL
A
B
C
D
E
F
G
H
I
K
L
M
Max.
Min.
Max.
Min.
MPL-06
224
169
M10*1.5P
16
134
45
35
15
5
70
--
35
18
(Ø 11 PCD 202)
MPL-08
265
210
M10*1.5P
20
154
57
47
16.5
6.5
84
26
40
18
(Ø 11 PCD 243)
MPL-10
315
254
M12*1.75P
23
182
67
51
21
5
100
32
50
18
(Ø 13 PCD 285)
MPL-12
375
304
M16*2P
25
202
72.5
56.5
21.5
5.5
120
36
60
18
(Ø 17 PCD 340)

SPEC.
/ MODEL
N
Piston
Area
(cm2)
Plunger
Stroke
(mm)
Jaw Stroke
<Diameter>
(mm)
Max.Gripping
Force
(kgf)
Max.Pressure
Setting
(kgf/cm2)
Max.Gripping
Force
(kgf)
Gripping Range
Max.
Min.
MPL-06
113.3
108
116
10
5.3
2597
10
1558
Ø35~Ø160
MPL-08
139.3
134
176
10
5.3
4729
12
2356
Ø40~Ø210
MPL-10
175.6
164
285
16
11.6
6576
14
2818
Ø50~Ø254
MPL-12
205.6
194
291
16
11.6
6715
14
2878
Ø50~Ø304
